G101EVN01.0 10.1 inch WXGA 1280x800
- Model:
- G101EVN01.0
G101EVN01.0 - Related Model
| Model | Version | |
|---|---|---|
| G101EVN01.0 | Ver5.0 | |
| G101EVN01.001 | Ver1.1 | |
| G101EVN01.0 |
G101EVN01.0 is a 10.1-inch a-Si TFT-LCD liquid crystal display module product launched by AUO. It features WLED backlighting, including an LED driver for backlighting, and is non-touch. This product operates within a temperature range of -20 to 60°C for operation and -30 to 70°C for storage. Its typical characteristics include white light LED backlighting, an LED driver, and reverse-mounted terminals. G101EV N01.0 can provide a display brightness of 300 cd/m² and a transmittance contrast ratio of 1300:1, with viewing angles of 85/85/85/85 (Typ.) (CR ≥ 10) (left/right/top/bottom). The optimal viewing angle is full-angle. Its response time is 25 (Typ.) (Tr + Td) ms. Due to the use of 6-bit gray-scale signals per pixel, this product can display 262K colors, with a color saturation of 45% (NTSC). The backlight employs WLED-lit side-illumination sources. The lifespan of the light source is 15K hours, with an LED driver included. G101EVN 01.0 uses a LVDS (1 channel, 6-bit) signal interface with a total of 40 pins and is connected via terminals. The driving voltage for the screen is 3.3V (Typ.). Its typical vertical refresh rate Fv is 60Hz. This model is used in industrial applications.
