BS062YQS-L32 6.2inch ADS

Brand: BOE

Model: BS062YQS-L32

Panel Type:LTPS TFT-LCD

Panel structure:FOB

panel size: 6.2"

Pixels H X V: 1080*2340

Display Color: 16.7M

Vertical Frequency: 60Hz

Response Time:30 ms

Signal voltage:-

Interface Type: -

View Angle:80/80/80/80

Color Space:NTSC 82%

Brightness: 0cd/m²

Contrast Ratio:1500:1

Power Dissipation: -

Backlight voltage: -

Backlight Life Time:-

Physical size : 67.272(H)×146.656(V)×0.3(D) mm

T-con board:-

Touch: In-Cell Touch,

Weight:

Temperature Range:Operating Temp.:-20 °C ~ 70 °C ; Storage Temp.:-30°C ~ 80 °C

Model:: BS062YQS-L32

BS062YQS-L32 - Related Model

Model	Version	PDF
BS062YQS-L32	Rev.P0

BS062YQS-L32 is a 6.2-inch LCD glass product from BOE Technology Group Co., Ltd. (BOE) featuring LTPS TFT-LCD technology. It lacks a backlight and features In-Cell Touch. It is recommended to use TD4320 and TD4321 driver ICs. The BS062YQS-L32 has a display resolution of 1080 (RGB) × 2340 and a 9:20 (width: height) aspect ratio. The pixels are arranged in RGB vertical strips. The calculated pixel density is 417 PPI. The display area measures 65.772 × 142.506 (width × height) mm, and the physical dimensions are 67.272 × 146.656 (width × height) × 0.3 (thickness) mm. The surface treatment is without a polarizer, and the glass substrate has a thickness of 0.15 + 0.15 mm. This product does not have a backlight. Its typical vertical refresh rate (Fv) is 60 Hz. It operates within a temperature range of -20 to 70°C for operation and -30 to 80°C for storage. Given its portrait mode, touchscreen capability, 6Q00=40 Cut, 6Q01=44 Cut features, this model is recommended for use in mobile devices.

BS062YQS-L32 Category :: Other
