ZJ070NA-01B 7 inch WSVGA TN
- Model:
- ZJ070NA-01B
ZJ070NA-01B - Related Model
| Model | Version | |
|---|---|---|
| ZJ070NA-01B | Final Ver02 |
ZJ070NA-01B is a 7.0-inch LCD module developed by Chimei Innolux, Inc., using a-Si TFT-LCD technology. It is fitted with a WLED backlight, no backlight drive, and no touch.The ZJ070NA-01B has a display resolution of 1024 (RGB) × 600 (WSVGA), an aspect ratio of 1710 (width: height), and pixels are arranged in RGB vertical strips. Its display area size is 153.6 × 90 (width × high) mm, viewing size is 156.4 × 92.8 (width × tall) mm, exterior size is 165.75 × 105.59 (width × height) × 3.6 (thick) mm, and net product weight is 113 g. Backlight aspects of this product uses 3S8P WLED side light source, the service life of the light source is 20K hours, without backlight drive. The ZJ070NA-01B features LVDS (1 ch, 8-bit) Signal interface, a total of 40 pins, FPC connection, drive screen voltage of 3.3 / 11.0 / 20.0 / -6.8 V (Typ.) (DVDD / AVDD / VGH / VGL). Its typical vertical refresh rate Fv is 60 Hz.Its working temperature is -20 ~ 60 ° C, and its storage temperature is -30 ~ 70 ° C.Based on its white LED backlight, up / down, left / right flip display, for IlsungTDS and other features, this model is recommended for portable navigators, digital photo frames, portable DVDs, MIDUMPC.
- ZJ070NA-01B Category :
- Other
- Specification
