SG2381G01-2 23.8 inch Quad-HD FFS
- Model:
- SG2381G01-2
SG2381G01-2 - Related Model
| Model | Version | |
|---|---|---|
| SG2381G01-2 | Ver1.1 |
The SG2381G01-2 is a 23.8-inch liquid crystal glass product developed by Shenzhen Xinghua Optoelectronics Technology Co., Ltd. (CSOT), featuring a-Si TFT-LCD technology. It lacks a backlight and a touch interface, with 8 source chips driving ICs integrated into it. The display resolution is 2560 (RGB) × 1440 (Quad-HD), with a 16:9 (width: height) aspect ratio and RGB vertical stripe pixel arrangement. Its display area dimensions are 526.848 × 296.352 (width × height) mm, and its physical dimensions are 534.84 × 307.848 (width × height) × 1.3 (thickness) mm. The surface treatment is matte (Haze 25%), hard coating (3H). The product weighs 520g (typical). It utilizes a glass substrate with a thickness of 0.50 + 0.50 mm. This product does not have a backlight. The SG2381G01–2 employs an LVDS (4 ch, 8-bit) signal interface with a total of 68 pins, connected via terminals, and has a driving voltage of 10.0V (typical). Its typical vertical refresh rate (Fv) is 100Hz. It operates within a temperature range of 0 to 50°C for operation and -20 to 60°C for storage. Given its sRGB, matte surface, and other features, this model is recommended for use in computer monitors and gaming applications.
- SG2381G01-2 Category :
- Monitor Panel
- Specification
