HV430QUB-N1K 43inch UHD ADS
- Model:
- HV430QUB-N1K
HV430QUB-N1K - Related Model
| Model | Version | |
|---|---|---|
| HV430QUB-N1K | Rev.O |
The HV430QUB-N1K is a 43-inch LCD glass product from BOE (BOE Technology) featuring a-Si TFT-LCD technology. It lacks a backlight and touch functionality. Its key characteristics are: sRGB, 10-bit grayscale, matte finish. Its operating temperature range is 0 to 50°C, and its storage temperature range is -20 to 60°C. This model is suitable for use in televisions. The product has been bonded with 6-source chips driving ICs. The HV430 QUB-N1K has a display resolution of 3840 (RGB) × 2160 (UHD), a 16:9 (width: height) aspect ratio, and RGB vertical stripe pixel arrangement. Its display area dimensions are 941.184 × 529.416 (width × height) mm, and its physical dimensions are 953 (width) × 543 (height) × 1.34 (thickness) mm. The surface treatment is matte (Haze 1%), hard coating (3H). The product weighs 1.58 kg (typical). It uses a 0.50 + 0.50 mm glass substrate. The device does not have a backlight. The HV430 QUB-N1K employs a V-by-One 8-lane signal interface with a total of 51 pins, connected via terminals, and has a driving voltage of 12.0V (typical). Its typical vertical refresh rate (Fv) is 60 Hz.
- HV430QUB-N1K Category :
- Monitor Panel
- Specification
