G084SN03 V3 8.4 SVGA 800x600

Brand: AUO

Model: G084SN03 V3

Panel Type:a-Si TFT-LCD

Panel structure:LCM

panel size: 8.4"

Pixels H X V: 800*600

Display Color: 262K/16.2M

Vertical Frequency: 60Hz

Response Time:20/10 ms

Signal voltage:3.3V

Interface Type: LVDS(6-bit)

View Angle:80/80/80/60

Color Space:NTSC 45%

Brightness: 250 cd/m²

Contrast Ratio:600:1

Power Dissipation: 3.66W

Backlight voltage: 28.8/32.85V

Backlight Life Time:30,000

Physical size : 142.5(H)×203(V)×5.7±0.5(D) mm

T-con board:Dorsal fold

Touch: No

Weight: 215.000 g

Temperature Range:Operating Temp.:-20 °C ~ 70 °C ; Storage Temp.:-20°C ~ 70 °C

Model:: G084SN03 V3

G084SN03 V3 - Related Model

Model	Version	PDF
G084SN03 V3	Ver2.3
G084SN03 V3

G084SN03 _ V3 is an 8.4-inch LCD module using a-Si TFT-LCD technology from AUO. It is equipped with WLED backlight, including LED driver backlight driver, no touch. As a TN, normal white display, transmission LCD module products, G084SN03 V3 can provide 250 cd / m2 display brightness 600: 1 transmission contrast,And a viewing angle of 80 / 80 / 80 / 60 (Typ.) (CR ≥ 10) (L / R / U / D). Its response time is 20 / 10 (Typ.) (Tr / Td) ms. With a 6-bit / 6-bit + FRC grayscale signal per pixel, this product can display 262 K / 16.2M color, and its display color saturation reaches 45% (NTSC). The backlight aspect of this product uses 3 strings WLED light source (bottom), the service life of the light source is 30K hours, including LED driver. The G084SN03 V3 uses an LVDS (1ch, 6 / 8-bit) signal interface with a total of 20 pins, with terminal connections and a drive voltage of 3.3 V (Typ.). Its typical vertical refresh rate Fv is 60 Hz.It has a working temperature of -20 ~ 70 ° C, a storage temperature of -20 ~ 70 ° C and a vibration resistance of 1.5G (14.7m / s2).Based on its easy-to-change backlight, white LED backlight, including LED drive, top / bottom, left / right flip display, 6 / 8 bit grey scale optional, surface fog surface, etc., this model is recommended for use in industrial and other products.

G084SN03 V3 Category :: Other
