G070Y3-T01_Ver2.5 is a 7.0-inch liquid crystal module developed by Chimei Innolux, Inc., using a-Si TFT-LCD technology. It is fitted with a WLED backlight, no backlight drive, and no touch.The G070Y3-T01 displays a resolution of 800 (RGB) × 480 (WVGA) with an aspect ratio of 17? 9 (W: H) and pixels arranged in RGB vertical strips. It has a display area dimension of 156 × 82.8 (wide × high) mm, a viewing dimension of 159.3 × 86.0 (wide × tall) mm, an appearance dimension of 168 × 94 (wide × height) × 6.65 (thick) mm, and a surface finish of fog ( Haze 25%), Hard coating (3H), Net product weight 180 g (Typ.). The backlight aspect of this product uses a 9S3P WLED light source (bottom), the service life of the light source is 30K hours, without backlight drive. G070Y3-T01 features TTL (1 ch, 6-bit) Signal interface, a total of 50 pins, FPC connection, drive screen voltage 3.3 / 10.5 / 18 / -7 V (Typ.) (VCC / AVDD / VGH / VGL). Its typical vertical refresh rate Fv is 60 Hz.Its working temperature is -30 ~ 85 ° C, storage temperature is -40 ~ 90 ° C, and vibration resistance is 3.0G (29.4m / s2).Based on its wide temperature, high brightness, backlight easy to change, white LED backlight, 180 degrees flip display, surface fog, Replaceable LED and other characteristics, this model is recommended for industrial, automotive display.
