B160QAN04.S 16 inch IPS
- Model:
- B160QAN04.S
B160QAN04.S - Related Model
| Model | Version | |
|---|---|---|
| B160QAN04.S | 0A | View & Download |
| B160QAN04.S | 97.16B14.S20 |
B160QAN04.S (Product Code: AUOF1A7) is a 16.0 inch a-Si TFT-LCD LCD module product introduced by AUO, it is equipped with WLED backlight, including LED driver backlight driver, no touch.The working temperature of this product is 0 ~ 50 ° C, the storage temperature is -20 ~ 60 ° C, and the vibration resistance is 1.5G (14.7m / s2).Its typical features are: 120Hz, white LED backlight, including LED driver, terminal flip, 10-bit gray scale, surface fog surface,G-Sync / FreeSync， OD, eDP1.4, DCI-P3:100%(CIE1976), LBL, Free-Sync, G-Sync, Adaptive Sync。This model is used in notebooks, games and other products.The B160QAN04.S has a display resolution of 3200 (RGB) × 2000 and an aspect ratio of 1610 (width: height). The pixels are arranged in RGB vertical strips. The pixel density calculated by the screen library is 235 PPI. Its display area size is 344.64 (wide) x 215.4 (high) mm, appearance size is 349.64 (width) x 224.4 (high) x 4.6 (thick) mm, surface treatment is fog surface, product net weight is 320 g (Max.) appearance style is thin screen (PCBA bend, thickness ≤ 3.0 mm).Backlight aspect of this product uses WLED light, the service life of the light source is 15K hours, including LED driver. The B160QAN04.S uses an eDP (4 Lanes) signal interface, a total of 40 pins, terminal connection, drive screen voltage of 3.3 V (Typ.). Its typical vertical refresh rate Fv is 120Hz.
- B160QAN04.S Category :
- Laptop panel
- Specification
